SWA39 SURF

Modular fixating system for contour and surface metrology

Surface and contour metrology ensures quality with regard to fine and coarse shape deviations of products and thus, ultimately, their functionality.

The reliability of the results as well as the level of the process costs also result decisively from how precise and secure the clamping of the test specimens is, how quickly a process-specific fixture is set up for this and how simple the repeatable positioning of parts is.

Efficient and secure processes

dk guarantees efficient and secure processes through proven, modular fixating fixtures and their excellent usability. The combination of the dk standard range of basic, add-on and clamping elements with positioning units specially developed for surface and contour measuring technology offers clear advantages.

 A modular system
High flexibility through an outstanding selection of combinable modules

• » Exactly adaptable to processes through function and size variants as well as accessories
• » Precision 3D spatial adjustments through infinite linear, rotation and tilting elements
• » Simple and rapid measurement set-ups due to the dk quick-change interfaces
• » Precise repeat fixation due to zero point clamping by means of stops
• » Minimisation of clamping forces for filigree parts: controlled, adjustable and reproducible
• » Robustly dimensioned and with hardcoat surfaces for long-lasting use
• » Universal utilisation together with other fields of quality assurance and also for laser marking
  through standardised SWA interfaces

You can find the brochure
with all products for
contour and surface metrology here
